AudioControl The EPICENTER Bass Restoration Processor Concert Series | The Epicenter (Black)
Specifications
- Brand
- AudioControl
- UPC
- 855814005860
- Category
- Digital Signal Processor
- Shipping weight
- 2.75 lb
Links open in a new tab; return here to finish shopping. Select Klarna, Shop Pay or Sezzle to learn how they work before checkout. Eligibility applies.
AudioControl The Epicenter (Black) is a digital signal processor. See the product details below for its intended application, specifications, and installation requirements.
- Brand: AudioControl
- Manufacturer part numbers: The Epicenter (Black), The Epicenter (White)
Features and product details
Increase bass response from your vehicle’s audio system with The EPICENTER Concert Series Digital Bass Restoration Processor by AudioControl. The EPICENTER contains patented bass maximization circuity that analyzes the incoming audio signal from your source unit, recreates missing bass tones, and transmits this low-frequency information back into the signal path to increase bass response. This digital bass restoration processor also features parametric bass control and a subsonic filter for fine tuning. Restore the earth-shaking power and heart-pounding bass your subwoofers crave!
FEATURES
- Patented Bass Maximizer™
- Dash mount control included (ACR-1)
- Bass restoration lighted display
- Parametric bass control
- PFM Subsonic Filter
- Balanced inputs
- Bass Output Control
SPECIFICATIONS
INPUTS
- Preamp Inputs: 1 (2 channels)
- Maximum Input Level: 15Vrms
- Input Impedance: 10kΩ
OUTPUTS
- Preamp Outputs: 1 (2 channels)
- Maximum Output Level: 13.5Vrms
- Output Impedance: 150Ω
PERFORMANCE
- Total Harmonic Distortion: 0.003%
- Frequency Response: 10Hz-100kHz
- Signal to Noise: 110dB
CONTROL
- Remote In
GENERAL
- Power Supply: High Headroom PWM Switching
- Current Draw: 150mA
- Recommended Fuse Rating: 1A
WEIGHTS & DIMENSIONS
- Dimensions: 8″W x 5.5″D x 1.2″H
- Weight: 1.8 lbs (0.8 kg)
Specifications
| Preamp Inputs | Preamp Inputs 1 (2 channels) |
|---|---|
| Maximum Input Level | Maximum Input Level 15Vrms |
| Input Impedance | Input Impedance 10kΩ |
| Preamp Outputs | Preamp Outputs 1 (2 channels) |
| Maximum Output Level | Maximum Output Level 13.5Vrms |
| Output Impedance | Output Impedance 150Ω |
| Total Harmonic Distortion | Total Harmonic Distortion 0.003% |
| Frequency Response | Frequency Response 10Hz-100kHz |
| Signal to Noise | Signal to Noise 110dB |
| Power Supply | Power Supply High Headroom PWM Switching |
| Current Draw | Current Draw 150mA |
| Recommended Fuse Rating | Recommended Fuse Rating 1A |
Box contents
EPICENTER Black/White
The Epicenter, ACR-1 Remote, Power Connector, Manual, Warranty
What's in the box
EPICENTER Black/White
The Epicenter, ACR-1 Remote, Power Connector, Manual, Warranty
